Kenz NSCPA-R TypeC
(Power Ascender for Rope Rescue)


NSCPA-R is available exclusively to rope rescue personnel
including fire departments, police, coast guard, and military.
For more detail
Please contact us if you have any questions.
Specification
※ Max operating load: 2.72kN
※ Compatible ropes: X-Monster SHIELD PRO or Marlow Ropes PROTEC 500 only
| Item | Specification | Notes | |
| Main Body | Weight | 5.9 kg | Cordless screwdriver not included |
| Dimensions | 250mm × 190mm × 160mm | Cordless screwdriver not included | |
| Compatible Rope | For use with X-Monster SHIELD PRO or Marlow Ropes PROTEC 500 only | Before use, always soak the rope in water for at least one night and dry in the shade to remove wax. | |
| Compatible Rope Diameter | 11.0mm–11.5mm | — | |
| Power Source | Cordless screwdriver (sold separately) | ※ Impact driver strictly prohibited | |
| Recommended Screwdriver | Cordless screwdriver with battery capacity of 36V 2.5Ah or higher and IPX6 or higher water resistance | 2,000 rpm or higher recommended | |
| Operating Range | Battery 40Vmax 2.5Ah, screwdriver at 2000rpm: approx. 50m | Battery 100% charged, 2.00kN load, ambient temp. 20°C | |
| Battery 40Vmax 5.0Ah, screwdriver at 2000rpm: approx. 100m | Battery 100% charged, 2.00kN load, ambient temp. 20°C | ||
| Max Gear Input RPM | 3,000 rpm | — | |
| Performance | Max Operating Load | 2.72kN | — |
| Ascent Speed | 2000 rpm: 8.0 m/min | 2.72kN load (ambient temp. 20°C) | |
| 2600 rpm: 10.0 m/min | 2.72kN load (ambient temp. 20°C) | ||
| 3000 rpm: 12.0 m/min | 2.72kN load (ambient temp. 20°C) | ||
| Descent Speed | Within 1.0 m/s (ambient temp. 20°C, load less than 2.00kN) | When the load is small or temperature is low, the grease inside the gearbox may harden, potentially preventing lowering. | |
| Within 0.5 m/s (ambient temp. 20°C, load 2.00kN or more) | |||
| Water/Dust Resistance | IP56 (When combined with an IPX6 rated cordless screwdriver, usable in rainy weather.) | IEC60529, JISC0920 | |
| Brake | Manual band brake | — | |
| Noise Level | 76 dB (cordless screwdriver operating sound) | In-house testing / noise meter | |
| Life Usage | No specific limit | — | |
| Warranty | 1 year, or 10 years with Maintenance Pack | Warranty details described in this manual | |
| Inspection Interval | Every 800 hours or every 3 years, whichever comes first | Additional charges apply. Free with Maintenance Pack. | |
| Operating Temp. | -10°C to 45°C | — | |
| Other | Accessories | Case ×1, Input tool ×1, Instruction manual ×1 | — |
| Continuous Use | 1 battery (under maximum operating load) | A 15-minute break is required after each battery use. (Precaution for cordless screwdriver use) | |
| Heat Protection | None | — | |
| Standard | CE certification and EN standard acquisition in progress | — |
※ Manage the torque of the cordless screwdriver to ensure the load does not exceed the maximum operating load.
※ This product is designed to perform optimally at an input rotation speed of 3,000 rpm.
※ Data may vary depending on the cordless screwdriver manufacturer and battery type.
※ Specifications are subject to change without notice at the company’s discretion.
